Kev qhia tshwj xeeb ntawm HCS7018-ET-P4S-UL bearing:

	Yam khoom NO.	HCS7018-ET-P4S-UL
	Bearing catalog	Kev kub ceev spindle bearing\|Spindle bearing
	Sab hauv txoj kab uas hla	90mm ua
	Sab nraud txoj kab uas hla	140 hli
	Dav	24 mm
	Sib cuag lub kaum sab xis	25 degree
	Tus naj npawb ntawm kab	Ib kab
	sealing hom	2 RSD- Ob lub foob\|Tsis tiv tauj
	Cage	Laminated ntaub tawb
	Precision	P4S (siab dua P4)
	Baisc dynamic load ntsuam xyuas	34 KN
	Basic static load ntsuas	24 KN
	Fatique load txwv	1, 81 KN
	Limiting ceev rau roj lubrication	16, 000 1/min
	Mass kwv yees.	1.18 kg ib

Bearing coding tsom xam:

HCS: ceramic pob bearings nrog cov ntsaws ruaj ruaj;
7: angular contact pob bearing;
18: loj series;
E: 25 degree kev sib cuag lub kaum sab xis;
T: lub nplhaib sab nrauv coj, phenolic reinforced fiber ntau laminated nylon qhov rais tawb;
P4S: AG tus qauv, P4S qib raug, siab dua DIN620 tus qauv P4;
U: ib leeg bearing, universal pairing;
L: lub teeb preloading.

Bearing designs, nta, thiab kev siv:

Spindle bearing with balls made from ceramic

HCS7018-ET-P4S-UL FAG thawj yog cov qauv tsim high-speed hybrid spindle bearing. Hom kabmob no muaj cov ntsaws ruaj ruaj ntawm ob sab thiab cov khoom me me ceramic. Hybrid spindle bearings tuaj yeem ncav cuag qhov nrawm nrog me ntsis tshav kub thiab hnav. Txawm nyob rau hauv high speeds, ib tug high degree ntawm rigidity yog khaws cia. Qhov no ua rau HCS7018-ET-P4S-UL FAGtshwj xeeb tshaj yog tsim rau siv nyob rau hauv high-speed-los yog sib tsoo spindles.

FAG spindle bearings yog ib kab, angular contact pob bearings uas tsis tuaj yeem dismantled. Lawv muaj cov khoom siv sab hauv thiab sab nrauv thiab cov pob-thiab-txheej cov rooj sib txoos nrog cov qhov rais qhov rooj. Vim lawv txoj kev ua siab ntev heev,lawv tshwj xeeb tshaj yog haum rau cov ntawv thov uas xav tau kev taw qhia siab thiab tsim nyog rau kev kub ceev. Spindle bearings feem ntau yog siv rau lub ntsiab spindles hauv cov cuab yeej siv tshuab.
