Technical specifications ntawm JU085XP0 bearing:

	Yam khoom NO.	JU085XP0
	Hom kabmob	Precision reali-slim nyias seem bearing\|Plaub taw tes tiv thaiv pob bearing (hom X)
	Sab hauv txoj kab uas hla	215.9 hli\|8.5in ib
	Sab nraud txoj kab uas hla	234.95 hli\|9.25 ib
	Thickness	12.7 hli\|0.5 nyob rau hauv
	Sib cuag lub kaum sab xis	30 degree
	sealing hom	Foob ntawm ob sab\|Hu rau
	Txwv ceev	265 r / min
	Basic dynamic load ntsuam xyuas, radial	9,59kn ua
	Basic static load ntsuam xyuas, radial	19kn ua
	Kwv yees li. Wt.	0.508 kg

Kev txheeb xyuas ntawm cov kabmob coding thiab bearing designs:

JU085XP0 Bearing kev txheeb xyuas

Lub "JU085XP0" bearing coding yuav muab faib ua rau feem: "J", "U", "085", "X", "P", "0". Cia peb kawm ua ke!

Duab

Standard one-piece formed ring with snap-over pockets- C X

ntu

Txoj hauj lwm 1 – Khoom siv

Txoj hauj lwm 2 – Series txheem hla ntu

Txoj Haujlwm 3, 4 thiab 5 - Qhov Loj (cov kabmob bore)

Txoj hauj lwm 6 – Bearing type

Txoj hauj lwm 7 - Separator - bearing hom sau tseg

Txoj hauj lwm 8 – Precision

Cov ntsiab lus tshwj xeeb

J- AISI 52100 Hlau

Ob lub foob - Nitrile roj hmab

Cov kabmob kaw

Extended dav-J| {{0}}.375 × 0.437 hauv

Extended dav-U| {0}.375 × 0.5 nti

Cov kabmob loj -8.5 nyob rau hauv txoj kab uas hla

"X"Baring type-Pob point contact ball bearing

PStandard ib-thooj tsim nplhaib nrog "snap-over" hnab ris- C, X

0-Kaydon Precision Class 1 rau ABEC 1F

Bearing nta thiab cov txiaj ntsig:

Conrad sib sau ua ke bearing tsim rau cov ntawv thov uas muaj ntau yam loads. Tshwj xeeb sab hauv geometry tso cai rau daim ntawv thov ntawm radial load, thrust load nyob rau hauv ob qho tib si kev taw qhia, thiab lub sij hawm load, tus kheej los yog nyob rau hauv ib tug ua ke.Ib qho plaub-point contact bearing tuaj yeem hloov ob lub bearings hauv ntau daim ntawv thov.

Kev siv cov kabmob:

JU085XP0 precision bearing yog nrov nyob rau hauv industrial machinery, aerospace thiab tiv thaiv, roj thiab roj, kev kho mob, semiconductor machinery, renewable zog, thiab lwm yam teb.

Optical scanning thiab imaging khoom

Mars Rover

Hlau roughnecks

Hnub ci vaj huam sib luag altitude-azimuth mountings
